Durable Nylon Woven Filter Cloth Less Jam Possibility Resisting Strong Alkali

PA(NYLON) FILTER CLOTH

Type

1. Monofilament PA Filter Cloth (1) PA filament yarn filter cloth (2) PA staple yarn filter cloth 2. Multifilament PA Filter Cloth (1) PA filament yarn filter cloth (2) PA staple yarn filter cloth

Monofilament PA Filter Cloth compared with Multifilament PA Filter Cloth

Performance of monofilament PA Filter Cloth:

Great permeability of air and water.
Less jam possibility.
Filter cake can be easily released and recycled.

Performance of multifilament PA filter cloth:

Great strength,especially its anti-abrasion is top-ranked in all general fibers.
Resist strong alkali and weak acid.
The strength expense can be ignored after dealt with NaoH(10%),as Polyamide is used 16h in the state of 90℃.
It’s continual applied temperature within 120℃ and the instant applied temperature can be up to 150℃.
PA 66 can not be applied in the field of Pharmacy and Food industry.

SPECIFICATION of monofilament PA filter cloth

MODEL .NO	WEIGHT (g/m2)	SPLITTING STRENGTH (N/5╳20cm)		SPLITTING AND ELONGATION(%)		AIR PERMEABILITY (mm/s)	THICKNESS (mm)
		WARP	WEFT	WARP	WEFT
PA5815	540	5340	2258	28.7	24.6	818	0.85
PA5133	590	7304	2550	37.8	26.5	619.4	1.00
PA2213	280	3111	1825	25.8	24.2	2268.36	0.52
PA2812 Dright	360	3585	2165	33.5	25.8	2239.12	0.65
PA2812	350	3780	2456

SPECIFICATION of Mutifilament PA Filter Cloth

MODEL NO	WEAVING	MATERIAL		DENSITY(radlx/10cm)		WEIGHT(g/m2)
MODEL NO	WEAVING	WARP	WEFT	WARP	WEFT	WEIGHT(g/m2)
407	Plain	Long thread	Long thread	240.8	187.2	195.4
663	Plain	Long thread	Long thread	192	156	263.8
601	Plain	Long thread	Long thread	132	160.8	222.6
301	Plain	Long thread	Long thread	275	250	106.8

MODEL NO	SPLITTING STRENGTH (N/5╳20cm)		SPLITTING AND ENLONGATION(%)		AIR PERMEABILITY (mm/s)	THICKNESS(mm)
MODEL NO	WARP	WEFT	WARP	WEFT	AIR PERMEABILITY (mm/s)	THICKNESS(mm)
407	1913	1539	59.4	46.4	29.7	0.42
663	2307	958	71.6	20.6	28.8	0.58
601	2500	1776	60	29.8	223.6	0.49
301	2016	1981	67	62.4	114.4	0.22

Usage

Widely used in the field of coal, petroleum, chemical, pharmacy, metallurgy and so on. More information about woven filter cloth, contact us.
